6400 Ocean Series
The Highlights
- Fully Strung Plate Boat
- Battery Enclosure for 2 x Batteries
- Able to flush mount up to a 16″ Sounder in Dash
- Weld in Rod Holders x 4
- Ally Bait Table w/Storage Tray, Drink Holders & 3 x Rod Holders
- Battery Isolator Recess & Hatch
- Ally Live Bait Tank Plumbed
- Rear Folding Lounge & Backrest
- Fabric Cabin Cushions
- Swim Platform Portside & Starboard
- Under Step Boarding Ladder S/S
Please note the images may include optional extras and/or modifications. Please note video is a 6500 Ocean Series Hard Top
View all features
Model Comparison
| 5600 | 6000 | 6400 | |
|---|---|---|---|
| Length Overall (m) | 5.95 | 6.45 | 6.85 |
| Beam (mm) (approx) | 2350 | 2450 | 2500 |
| Material Bottoms 5083 High Tensile | 4mm | 4mm | 5mm |
| Material Sides 5083 High Tensile | 4mm | 4mm | 4mm |
| Fuel Tank Size (approx) | 150L | 180L | 180L |
| Freeboard (approx mm) | 700 | 730 | 750 |
| Deadrise (Fast Planing Hull) | Variable | Variable | Variable |
| Transom | L/S | X/L | X/L |
| Min Horsepower (Hp) | 115 | 140 | 150 |
| Max Horsepower (Hp) | 150 | 175 | 200 |
| Hull Weight (approx Kg) | 675 | 765 | 914 |
| Number of People (up to) | 6 | 7 | 7 |
Standard Features
| 5600 | 6000 | 6400 | |
|---|---|---|---|
| Ally Live Bait Tank Plumbed with Rule 800GPH Pump | ✓ | ✓ | ✓ |
| Walk Thru Transom | ✓ | ✓ | ✓ |
| Swim Platform Stbd | 300mm | 400mm | 400mm |
| Swim Platform Portside | 300mm | 400mm | 400mm |
| Under Step S/S Boarding Ladder (Stbd) | ✓ | ✓ | ✓ |
| Side Pockets x 2 | ✓ | ✓ | ✓ |
| Battery Enclosure for 2 x Batteries w/1 Hatch | ✓ | ✓ | ✓ |
| Battery Isolator Recess with Hatch | ✓ | ✓ | ✓ |
| Seats Deluxe incl Bolster | 2 | 2 | 2 |
| Drivers Seat Slide | ✓ | ✓ | ✓ |
| Rear Folding Lounge & Backrest | ✓ | ✓ | ✓ |
| Cabin Cushions (Fabric) (Full Height Head Room) | ✓ | ✓ | ✓ |
| Lined Cabin | ✓ | ✓ | ✓ |
| Foot Rest (Driver & Passenger) | ✓ | ✓ | ✓ |
| Heavy Duty 3 Piece Reinforced Windscreen | ✓ | ✓ | ✓ |
| Aluminium Weld in Rod Holders | 4 | 4 | 4 |
| Ally Bait Table with Storage Tray, Drink Holders & 3 x Rod Holders | ✓ | ✓ | ✓ |
| Cleats | 3 | 3 | 3 |
| LED Nav & Stern Lights | ✓ | ✓ | ✓ |
| Bilge & Bait Pumps | ✓ | ✓ | ✓ |
| 6 Gang Switch Panel | ✓ | ✓ | ✓ |
| Isolator Switch | ✓ | ✓ | ✓ |
| Hydraulic Steering Seastar | ✓ | ✓ | ✓ |
| Large Carpeted Anchor Well with Drain | ✓ | ✓ | ✓ |
| Carpeted Hardwood Floor | ✓ | ✓ | ✓ |
| Bow Sprit & Bow Roller | ✓ | ✓ | ✓ |
| Bow Rails & Side Rails | 32mm | 32mm | 32mm |
| Transom Rails x 3 | 25mm | 25mm | 25mm |
| Raised Sheerline | ✓ | ✓ | ✓ |
| Painted White w/Stripes | ✓ | ✓ | ✓ |
| Reverse Chines | ✓ | ✓ | ✓ |
| Spray Chines Full Length | ✓ | ✓ | ✓ |
| Transducer Brackets | 2 | 2 | 2 |
| Transom Tie Down Lugs | 2 | 2 | 2 |
| Transom Deck Tread | ✓ | ✓ | ✓ |
Optional Extras
VHF Radio
Lowrance Sounder
Simrad Sounder
Aluminium Cockpit Floor wScuppers
Kill Tank Plumbed
Ally Rocket Launcher
Deck Wash System
Bunk In Fill Board with Fabric Cushions
Paint Upgrade
